Wa t l o w S e r i e s S D L i m i t
■
5
■
C h a p t e r 2 I n s t a l l a n d W i r e
1/4 DIN Series SD Limit Dimensions
Model
Number
108.3 mm
(4.26 in)
108.8 mm
(4.28 in)
103.5 mm
(4.08 in)
9.6 mm
(0.38 in)
Customer Front Panel
0.5 mm (0.020 in) maximum gap between
controller front and customer front panel
99.8 mm
(3.93 in)
99.8 mm
(3.93 in)
92.0 to 93.0 mm
(3.62 to 3.65 in)
Panel Cutout
Panel Thickness
1.52 to 9.53 mm
(0.060 to 0.375 in)
92.0 to 93.0 mm
(3.62 to 3.65 in)
17.6 mm
(0.68 in)
minimum
16.0 mm
(0.63 in)
minimum
RESET RESET
Side
Back
Front
99.8 mm
(3.93 in)
52.8 mm
(2.08 in)
92.0 to 93.0 mm
(3.62 to 3.65 in)
Panel Cutout
Panel Thickness
1.52 to 9.53 mm
(0.060 to 0.375 in)
45.0 to 45.6 mm
(1.77 to 1.79 in)
31.8 mm
(1.25 in)
minimum
7.9 mm
(0.31 in)
minimum
RESET RESET
Dimensions for Horizontal or Vertical versions
100.2 mm
(3.95 in) 10.3 mm
(0.40 in)
Customer Front Panel
0.64 mm (0.025 in) maximum gap between
controller front and customer front panel
Model Number
97.8 mm
(3.85 in)
60.9 mm
(2.40 in)
97.8 mm
(3.85 in)
60.9 mm
(2.40 in)
Model Number
92.0 to 93.0 mm
(3.62 to 3.65 in)
Panel Cutout
Panel Thickness
1.52 to 9.53 mm
(0.060 to 0.375 in)
45.0 to 45.6 mm
(1.77 to 1.79 in)
31.8 mm
(1.25 in)
minimum
7.9 mm
(0.31 in)
minimum
99.8 mm
(3.93 in)
52.8 mm
(2.08 in)
RESET RESET
1/8 DIN Series SD Limit Dimensions
Back (horizontal)
Side (horizontal)
Front (vertical)
Back (vertical)
Front (horizontal)
Contact your local Greenlee supplier for the appropriate punch kit and
cutout tools required for rapid mounting.
Contact your local Greenlee supplier for the appropriate punch kit and
cutout tools required for rapid mounting.
