Wa t l o w S e r i e s S D L i m i t
■
1 9
■
C h a p t e r 3 K e y s a n d D i s p l a y s
Keys and Displays
3
RESET
2 3 1
LIMIT SD
2 3 2 3 1 SD LIMIT SD SD LIMIT SD
RESET
LIMIT SD
1 2
RESET
1
2
3
1
LIMIT SD
SD SD SD LIMIT SD
RESET
1 2 3
LIMIT SD
1
1 2 3 %
RESET
1 2 3 2 3
LIMIT SD
1
1/4 DIN
1/8 DIN Horizontal 1/16 DIN 1/32 DIN
1/8 DIN Vertical
Advance Key
Advances the lower dis-
play through parameter
prompts.
RESET Key
• Returns to the Home
Page.
• Resets a latching
alarm
• Resets a latching in-
put sensor error.
• Resets the limit.
• Silence an alarm
Up and Down
Keys
In the Home Page, ad-
justs the limit set point.
In other pages, changes
the upper display to a
higher or lower value.
Active Output
Indicator Lights
Lit when the correspon-
ding limit or alarm out-
put is tripped.
1 2 3 RESET
RESET
2 3 1
LIMIT SD
2 3 2 3 1
Upper Display (Left Display on 1/32 DIN): Indicates the
process in the Home Page, or the value of the parameter in
the lower display in other pages.
Lower Display (Right Display on 1/32 DIN): Indicates the
set point or output power value during operation, or the pa-
rameter whose value appears in the upper display.
SD LIMIT SD SD LIMIT SD
RESET
LIMIT SD
1 2
1/32 DIN
Note: After 60 seconds with no key presses, the controller reverts to the Home Page.
