C h a p t e r 3 K e y s a n d D i s p l a y s
Setup Page
[`Sen] Sensor Type
[`Lin] Linearization
[`C-F] Temperature Units
[S;deC] Temperature Decimal Places
[P;dEC] Process Decimal Places
[IS;En] InfoSense Enable
[IS;P1] InfoSense Point 1
[IS;P2] InfoSense Point 2
[IS;P3] InfoSense Point 3
[IS;P4] InfoSense Point 4
[Sc;Lo] Process Scale Low
[Sc;hi] Process Scale High
[P1;LE] Process Input Low Error
[P1;HE] Process Input High Error
[rg;Lo] Units Scale Low
[rg;hi] Units Scale High
[SP;Lo] Set Point Low Limit
[SP;hi] Set Point High Limit
[`CAL] Calibration Offset
[Ftr;E] Enable Input Filter
[FLtr] Filter Value
[Ot~1] Output 1 Function
[LSd1] Limit 1 Sides
[hyS1] Limit 1 Hysteresis
[Ot`2] Output 2 Function
[LSd2] Limit 2 Sides
[hyS2] Alarm or Limit 2 Hysteresis
[Lgc2] Alarm 2 Logic
[LAt2] Alarm 2 Latching
[SiL2] Alarm 2 Silencing
[dSP2] Alarm 2 Message
[Ot`3] Output 3 Function
[LSd3] Limit 3 Sides
[hyS3] Alarm or Limit 3 Hysteresis
[Lgc3] Alarm 3 Logic
[LAt3] Alarm 3 Latching
[SiL3] Alarm 3 Silencing
[dSP3] Alarm 3 Message
[AO3;U] Analog Output 3 Units
[O3;Lo] Analog Output 3 Scale Low
[O3;hi] Analog Output 3 Scale High
[r3;So] Output 3 Retransmit Source
[r3;Lo] Output 3 Retransmit Low Scale
[r3;Hi] Output 3 Retransmit High Scale
[r3;CO] Output 3 Retransmit Offset
[I;Err] Input Error Latching
[UdSP] Upper Display Look
[LdSP] Lower Display Look
[Addr] Modbus Device Address
[bAud] Baud Rate
[`LOC] Lockout
*
‰
Setup Page Overview
The Setup Page contains parameters that define
the basic limit functions. Go to the Setup Page for
initial configuration or if your application require-
ments change. Be sure to program the Setup
Page first!
To go to the Setup Page, press both the Up ¿ and
Down ¯ keys for three seconds from the Home
Page.
• Press the Advance Key ‰ to move through
the parameter prompts.
• Press the Up ¿ or Down ¯ keys to change
the parameter value.
• Press the RESET Key at any time to return
to the Home Page.
[`SEt]
[PAgE]
Note: Hardware configuration and programming selections deter-
mine what parameters appear in the Setup Page.
* Note: For FM Approval, the [[` `L LO OC C]] parameter must be set to 3 or
the limit must be remotely mounted to restrict casual user adjust-
ment.
