Wa t l o w S e r i e s S D L i m i t

31

C h a p t e r 6 O p e r a t i o n s

Display

Parameter Name

Description

Settings

Range

(Integer values for Modbus

in parentheses.)

Default

Modbus*

(less 40,001

offset)

Read/Write

Appears if:

Note: Parameters appear in the Operations Page only if activated from the Programming Page.

Note: Some values will be rounded off to fit in the four-character display. Full values can be read with Modbus. All temperature parame-
ters are in °F through Modbus.

* Low register numbers contain the two higher bytes; high register numbers contain the two lower bytes of the four-byte integer. Decimal
precision is implied at three decimal places unless otherwise noted.

[A3;hi]

[A3.hi]

Alarm 3 High

Set the high alarm set point for Output
3.

Process: range of sensor, if
[`SEN] is set to [``tc] or
[`rtd]

-1999 to 9999 if

[`SEN] is

set to

[`Ma], [uolt], or

[`Mu].
(-1999000 to 9999000)

1500

*134, 135
R/W

If

[Ot~3] is set to

[Pr;AL]

hyS1]
[hyS1]

Limit 1 Hysteresis

Set the hysteresis for the limit. This de-
termines how far into the safe region the
input needs to move before the limit can
be cleared. This also appears in the Set-
up Page.

0.0 to 999.0
(0000 to 999000)

1.0

*106, 107
R/W

Always active.

[hyS2]
[hyS2]

Output 2 Hysteresis

Set the hysteresis for the alarm or limit
output. This determines how far into the
safe region the input needs to move be-
fore the output can be cleared.

0.0 to 999.0
(0000 to 999000)

1.0

*121, 122
R/W

[Ot`2] is set to [Pr;;AL]
or

[LIM].

[hyS3]
[hyS3]

Output 3 Hysteresis

Set the hysteresis for the alarm or limit
output. This determines how far into the
safe region the input needs to move be-
fore the output can be cleared.

0.0 to 999.0
(0000 to 999000)

1.0

*136, 137
R/W

[Ot`3] is set to [Pr;;;AL]
or

[LIM].

[Addr]
[Addr]

Modbus Device Address

Set the device address for communica-
tions. Every controller on a network
must have a unique address.

1 to 247

1

This can
only be set
from the
controller
front
panel.

Output 2 is a commu-
nications output.

SD_ _ - _ _ U _ - _ _ _ _

[`C-F]
[ C-F]

Temperature Units

Set the temperature units for thermocou-
ple and RTD inputs.

[```F] Fahrenheit (0)
[```C] Celsius (1)

[```F] (0)

40 R/W

[`Sen] is set to [``tc]

or

[`rtd].

[`Cal]

[ CAL]

Calibration Offset

Offset the input reading.

-999 to 999
(-999000 to 999000)

0

*85, 86
R/W

Always appears.
