Wa t l o w S e r i e s S D L i m i t ■ 34 ■ C h a p t e r 8 F a c t o r y
Display Parameter Name
Description
Settings Range
(Integer values for Modbus
in parentheses.)
Default Modbus*
(less 40,001
offset)
Read/Write
Appears if:
Factory Page and Calibration
8
To go to the Factory Page, press both the Up ¿ and Down ¯ keys for six seconds from the Home Page. {Fact} will
appear in the upper display and
{page} in the lower display.
• Press the ‰ Advance Key to move through the parameter prompts.
• Press the Up ¿ or Down ¯ keys to change the parameter value.
• Press the RESET Key at any time to return to the Home Page.
[AMb]
[AMb]
Ambient Temperature
Displays the current calculated ambient
temperature.
-50.0 to 300.0°F NA 268 R
269 R Always active.
[A;mn]
[A.Mn]
Minimum Recorded Ambient
Temperature
Displays the minimum recorded ambient
temperature.
-50.0 to 300.0°F NA NA Always active.
[A;ma]
[A.MA]
Maximum Recorded Ambient
Temperature
Displays the maximum recorded ambient
temperature.
-50.0 to 300.0°F NA NA Always active.
[DSPL]
[dSPL]
Display Intensity
Increase or decrease the brightness of the
upper and lower display.
15 to 100% duty 100 NA Always active.
[rESt]
[rESt]
Restore Factory Calibration
Replaces the user calibration parameters
with the factory calibration parameters.
[~~no] (0)
[~yES] (1) [~~no] (0) 199 R/W Always active.
[Usr;r]
[Usr.r]
Restore User Settings
Restores customer configured settings.
Two sets of user settings are available.
[~~no] (0)
[Set1] (1)
[Set2] (2) [~~no] (0) 200 R/W Always active.
[USr;S]
[USr.S]
Save User Settings
Saves customer configured settings. Two
sets of user settings are available.
[~~no] (0)
[Set1] (1)
[Set2] (2) [~~no] (0) 201 R/W Always active.
[dFLt]
[dFLt]
Default Parameters
Reset all parameters to their
default values.
[~~no] (0)
[~yES] (1) [~~no] (0) 198 R/W Always active.
[O;ty1]
[O.ty1]
Output 1 Type
Displays the hardware type for Output 1.
[rLAY] mech. relay (2) [rLAY]
mech. relay
(2) 193 R Always active.
