Watlow Series SD Limit - Manual (Page 53)

S D L — —
DIN Sizes 3, 6, 8, 9 or 4
3 1/32 DIN
6 1/16 DIN
8 1/8 DIN Vertical
9 1/8 DIN Horizontal
4 1/4 DIN
Control Type L*
L Limit Control
Power Supply H or L
H 100 to 240VÅ (ac)
L 24V‡ (ac/dc)
Output 1 J
J Mechanical Relay Form A, 2 Amp
Output 2 A, C, K, J or U
A None
C Switched DC
K Solid-state Relay Form A, 0.5 Amp
J Mechanical Relay Form A, 2 Amp
U EIA/TIA-485 Modbus Communications
A None
C Switched DC/Open Collector
K Solid-state Relay Form A, 0.5 Amp
F Universal Process
E Mechanical Relay Form C, 5 Amp
Infrared comms options A or R
A None
R Infrared Communications Ready (not available on 1/32 DIN)
Display Colors and Custom options RG or RR
RG Red Green
RR Red Red (Not available on 1/32 DIN)
Wa t l o w S e r i e s S D L i m i t
■
5 1
■
A p p e n d i x
Ordering Information and Model Numbers
*UL-approved PID control and PID profiling versions are available. For more information, go to
www.watlow.com or contact your local Watlow representative.
J
Output 3 (not available on 1/32 DIN) A, C, K, F or E
A
