Factory Page
[AMb] Ambient Temperature
[A;mn] Minimum Recorded Ambient Temperature
[A;ma] Maximum Recorded Ambient Temperature
[DSPL] Display Intensity
[rESt] Restore Factory Calibration
[Usr;r] Restore User Settings
[USr;S] Save User Settings
[dFLt] Default Parameters
[O;ty1] Output 1 Type
[O;ty2] Output 2 Type
[O;ty3] Output 3 Type
[`S;Id] Software ID
[S;UEr] Software Version
[S;bld] Software Build Number
[PWr] Power Type
[`Sn-] Serial Number 1
[`Sn_] Serial Number 2
[tc;50] Thermocouple, 50mV
[tc;00] Thermocouple, 0mV
[tc;32] Thermocouple, 32°F
[`r;15] RTD, 15 ohm
[r;380] RTD, 380 ohm
[``U;1] Input Calibrate, 1.0 Volt
[``U;9] Input Calibrate, 9.0 Volt
[``A;4] Input Calibrate, 4.0 mA
[`A;16] Input Calibrate, 16.0 mA
[03;1u] Output 3 Calibrate, 1.0 Volt
[03;9u] Output 3 Calibrate, 9.0 Volt
[03;4A] Output 3 Calibrate, 4.0 mA
[03;16] Output 3 Calibrate, 16.0 mA ‰
Factory Page Overview
The Factory Page contains information on diagnostics,
calibration and restore-parameter functions.
To go to the Factory Page, press both the Up ¿ and
Down ¯ keys for six seconds from the Home Page.
• Press the Advance Key ‰ to move through the pa-
rameter prompts.
• Press the Up ¿ or Down ¯ keys to change the pa-
rameter value of Read/Write (R/W) parameters.
• Press the RESET Key at any time to return to the
Home Page.
Note: Hardware configuration and programming selections deter-
mine what parameters appear in the Factory Page.
[FAct]
[page] Programming Page Overview
The Programming Page determines what parameters
the user wants to appear in the Operations Page. Se-
lect a parameter for any of the 16 Programming Page
locations, P1 to P16. These now appear in the Opera-
tions Page. All 16 locations have parameters selected
as defaults.
To go to the Programming Page, hold down the RESET
key, then press the Advance Key ‰, and hold both
down for about six seconds.
• Press the Advance Key ‰ to move through the pa-
rameter prompts.
• Press the Up ¿ or Down ¯ keys to change the pa-
rameter value.
• Press the RESET Key at any time to return to the
Home Page.
Note: The hardware configuration and programming selections will
also determine what parameters appear in the Operations Page. A
Programming Page selection will not appear in the Operations
Page if the parameter is not active.
[Prog]
[PAgE]
Programming Page
[~~P1] Parameter Location 1 (48)
[~~P2] Parameter Location 2 (49)
[~~P3] Parameter Location 3 (50)
[~~P4] Parameter Location 4 (51)
[~~P5] Parameter Location 5 (52)
[~~P6] Parameter Location 6 (53)
[~~P7] Parameter Location 7 (54)
[~~P8] Parameter Location 8 (55)
[~~P9] Parameter Location 9 (56)
[~P10] Parameter Location 10 (57)
[~P11] Parameter Location 11 (58)
[~P12] Parameter Location 12 (59)
[~P13] Parameter Location 13 (60)
[~P14] Parameter Location 14 (61)
[~P15] Parameter Location 15 (62)
[~P16] Parameter Location 16 (63) ‰
[nonE]
[``P1]
.
. (48)*.
.
[`P16]
(63)*
*Programming Page parameters Modbus register numbers
P1 through P16 are 48 through 63
Calibration information for the Series SD controllers is available
in pdf format. Go to www.watlow.com > Literature > Product
User Manuals and search on Series SD Calibration Manual.
