6.2 WATLOW Series 988LF Users Manual Factory Menus, Chapter 6
Factory Ship Date
Shows the date that the final factory control test was performed. The
first two digits represent the week as numbered from [01``] to [52``].
The second two digits represent the year [``97], [``98], etc…
[dAtE] This prompt always appears.
Software Revision
Shows the controller’s software revision code. This letter indicates the
software revision of your controller; [50`d].
[SOFt] This prompt always appears.
Serial Number
Shows the controller’s serial number. The first two letters in the upper
display are to indicate that the controller is in serial number mode. The
right half of the upper display shows the first two digits of the serial num-
ber. The lower display shows the last four digits of the serial number.
[Sn34]
[5678]
This is what the controller with the serial number 0988345678 would
display.
[Sn``] This prompt always appears.
Ambient Temperature
Shows the ambient temperature at the Input 1 terminals. The tem-
perature is shown in °F in the form [00)0] regardless of the settings of
[deC1], [deC2], [`dfL], or [`C_F].
[AMb] This prompt always appears.
Factory Use Only
These prompts are used only at the factory.
[Acnt] [`gnd] [cnt1] [cnt2] These prompts always appear.
[Acnt]
[`gnd]
[cnt1]
[cnt2]
[Sn--]
[SOFt]
[dAtE]
[AMb]
Factory-Diagnostics
