Introduction
Introduction
Using this Manual
This manual provides the information you will need to install and operate
a Series 988LF controller.
If you need information about Series 988LF configurations and model
numbers, refer to the Appendix of this manual.
This manual explains the five steps of setting up a Series 988LF con-
troller:
1. Set and document all of the DIP switches, if applicable: Chapter 1.
2. Mount the controller: Chapter 2.
3. Wire and document the controller wiring: Chapter 2.
4. Configure and document the controller software: Chapters 3-6.
5. Run, test and adjust your application. Update documentation.
The Appendix provides definitions and specifications, along with
application examples to help you optimize the safety and perfor-
mance of your application. Use the Table of Contents and Index to
find specific information.
Document Every Step
The Series 988LF provides powerful control features. Carefully document
each step of the setup and any subsequent changes. This will make it
much easier to change, adjust and troubleshoot your application.
Make the configuration documentation available to engineers and techni-
cians, on all shifts, who may need to work with the Series 988LF. We pro-
vide space in this manual to record configurations. You may prefer to
photocopy the blank forms and keep them in a separate binder. However,
you maintain your documentation; be sure to replace all old copies of the
documentation with updated versions whenever the controller configura-
tion is changed.
NOTE:
The Menu Overview
in the Appendix
shows all of the
menus and
prompts.
NOTE:
The 12-digit number
is printed on the top
of the stickers on
each side of the
controller’s case
and on the right-
hand or top circuit
board.
