Operations
5.6 WATLOW Series 988LF Users Manual Operations Menu, Chapter 5
Alarm Hi
Select the high trigger value for the output 2 alarm. Represents the
high process alarm or high deviation alarm.
[`AHI] This prompt appears only if [`Ot2] parameter is set to [``AL] or
[`ALn].
If Default
↓ ↓
value of highest
[``Pr] [`ALO] … [`rH1] (or [`rH2]) … value of
[`AL0] [`AHI] in Setup Menu sensor
range
[``dE] [```0] … [`999] … [9999]
[`AL0] [[`AHI] [[`AH]1 [`AH1]
[`AHI]
Alarm Lo
Select the low trigger value for the output 2 alarm. Represents the low
process alarm or low deviation alarm.
[`ALO] This prompt appears only if [`Ot2] parameter is set to [``AL] or
[`ALn].
If Default
↓ ↓
lowest value of
[`Pr1] value of … [`rL1] (or [`rL2]) … [`AHI]
[`AL0] sensor in Setup Menu [`ALO]
range
[`dE1] [-999] … [```0]
`AL0] [`ALO] [`ALO]
[`AL0
