Program prompts and description, Table 10, Program – Watlow Series 920 Microprocessor-Based Ramping Control User Manual
Page 50

Table 10 -
PROGRAM Prompts
and Description.
NOTES:
The Series 920 leaves the factory programmed for a warm start. STOP
steps appear as a defautt until you program your 920.
Make photocopies, keep original clean.
PROGRAM
Prompt 1 Description
FILE?
I Current system file to edit.
Range
1-10
Default
1
Your Settings
STEP Select step number to view or edit. Press MODE for step-type
prompt. To change steptype use the increment/decrement
key and press ENTER.
1-99
1
EV1
Enter the Event Output 1 status.
Off or ON
- -
Ev2
Enter the Event Output 2 status.
OFF or ON
- -
RETURN
Press the
ENTER
key to return
to the SYSTEM prompt.
1
Press the MODE key to return to the STEP prompt.
I
JUMPLOOP -
StepType
JS
I
Enter the step number the 920 will jump to.
1-99
I
1
I
JC
Enter number of times the 920 will jump to the step
indicated by JS. 0-100 0
RETURN
Press the ENTER key to return to the SYSTEM prompt
Press the MODE key to return to the STEP prompt.
WAITFOR - Step-Type
WPV
Enter a process variable to compare with the actual
temperature.
WHR Enter the hours the
920 will wait relative to the beginning
of the step.
WMN Enter the minutes the 920 will wait relative to the beglnnlng
of the step.
RETURN
Press the ENTER key to return to the SYSTEM prompt
RAL to RAH
- -
0 - 23 hours
-
0 - 59 minutes
-
1 Press the MODE key to return to the STEP prompt.
I
AUTOSTART - Step-Type
DAY
1
Enter the number of days for the 920 to wait until
I
I
AUTOSTART takes place. 0 - 6days ---
HOUR
Enter the number of hours for the 920 to wait for the time-of-
day dock before AUTOSTART takes place.
0 - 23 hours
- -
MIN Enter the number of minutes for the 920 to wait for
day clock before AUTOSTART takes place. 0 - 59 minutes -
RETURN
Press the ENTER key to return to the SYSTEM prompt.
Press the MODE key to return to the STEP prompt.
STOP - Step-Type
STOP
Press ENTER to display the last step of the program.
RETURN
Press the ENTER key to return to the SYSTEM prompt.
Press the MODE key to return to the STEP prompt.
LINK - StepType
FILE? 1 The current system file will always link to
Step 1 in the file specified. 1-10 1
RETURN Press the ENTER key to return to the SYSTEM prompt.
Press the MODE key to return to the STEP prompt
50
WATLOW Series 920 User’s Manual How To Program the Serles 920, Chapter 6
