4.

5.

6.

7.

Use the UP/DOWN keys to place hours into the display. The display will flash

until you press ENTER.

Press MODE to continue to the MIN parameter and press ENTER. Enter the cor-
rect value for minutes and press ENTER.

Press the MODE key several times to return to the top of the ACCESS (0) menu.

At the top of the ACCESS (0), which is the CALIB menu, you will see the Real

Time (Tl) displayed.

Continue to press MODE until you reach RETURN. Press ENTER to return to
SYSTEM.

Before Entering Your Program

Before we begin to program your Series 920, there are a few other initial SETUP

parameters to enter. Verify that DIP switch #7 is OFF. If you have not tried any
programming since your cold start, the C/F/U (Celsius/Fahrenheit/Units) and GS

(Guaranteed Soak) parameters are set to their appropriate values. Refer to the glos-
sary for a more detailed definition. If you have already tried stepping through the
parameters and entering values, it might be a good idea to go back and double check

to see that the values are correct.

1.

2.

3.

4.

5.

Press the MODE key until SETUP appears. Press ENTER. Once again you see

the ACCESS parameter. Use the UP/DOWN keys to enter (5) and press ENTER;
this is the Special Function (SPCLFUNC) menu.

Press MODE again until you see the C/F/U parameter. This parameter will defautt

to F. Use the UP/DOWN keys to enter degrees F (Fahrenheit). Press ENTER..

Continue through the SPCLFUNC menu

until you see GS

(Guaranteed Soak).

Enter a value of (0); press ENTER. This parameter has a default of 0.

Press the MODE key to move to the RETURN parameter. Press ENTER to return

to SYSTEM.

Good job! You have completed the initial setup, and are ready to program the 920.

Programming. File

1

Our first step in programming will be to make a short ramp and soak program. Step 1

initializes the set point to a known starting point for the ramp, Step 2 is a short ramp,
Step 3 is a soak step, which holds the programmed set point constant for the pro-

grammed time. Step 4 will be a STOP step which signals the end of a file.

1.

2.

3.

From the SYSTEM menu, press MODE until you see the PROGRAM menu.
Press ENTER.

The Series 920 asks you for a FILE?. Your 920 should already say (I), but if you

have entered any values, it may be different. Make sure it says (1). Press ENTER.

Press the MODE key and you are asked for a STEP. ENTER (1) if it is not already

there.

NOTE:

When either the

hours or minutes are

entered, internal

seconds are set to 0.

NOTE:

DIP switch #7 must
be OFF to access all

SPCLFUNC parame-

ters.

Sample Program, Chapter 3

WATLOW Series 920 User’s Manual

15
