AFL2-10A-N28 Panel PC

Page 44

3.12.5 USB Device Connection

NOTE:

User must install the USB 3.0 driver before connecting a USB device to

the system or else the system may not recognize the connected

device.

There are two USB 2.0 connectors and two USB 3.0 connectors on the AFL2-10A-N28. To

connect a USB device, please follow the instructions below.

Step 1:

Locate the USB connectors. The locations of the USB connectors are shown

in Chapter 1.

Step 2:

Align the connectors. Align the USB device connector with one of the

connectors on the AFL2-10A-N28. See Figure 3-32.

Figure 3-32: USB Device Connection

Step 3:

Insert the device connector. Once aligned, gently insert the USB device

connector into the onboard connector.
