AFL2-10A-N28 Panel PC
Page 119
15 EC_EPP_PD6 16 EC_EPP_PE
17 EC_EPP_PD7 18 EC_EPP_SLCT
Table 7-7: EC Debug Connector (CN1) Pinouts
7.2.7 HDD Connector (JSATA1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 VCC12
3 NC 4 VCC12
5 NC 6 NC
7 GND 8 VCC5
9 SATA_RXP0_C 10 VCC5
11 SATA_RXN0_C 12 VCC5
13 GND 14 VCC5
15 SATA_TXN0_C 16 GND
17 SATA_TXP0_C 18 VCC3
19 GND 20 VCC3
Table 7-8: HDD Connector (JSTAT1) Pinouts
7.2.8 Hot Key LED Connector (HOTKEYLEDCN1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 KEYLED1 2 KEYLED2
3 KEYLED3 4 KEYLED4
5 KEYLED5 6 KEYLED6
7 GND 8 VCC3
Table 7-9: Hotkey LED Connector (HOTKEYLEDCN1) Pinouts
