AFL2-10A-N28 Panel PC
Page 9
1.3 Internal Overview
The AFL2-10A-N28 has the following components installed internally:
ƒ 1 x Motherboard
ƒ 1 x 2.0 GB 1066 MHz DDR3 SO-DIMM
ƒ 1 x 802.11b/g/n wireless LAN module
1.4 System Specifications
The technical specifications for the AFL2-10A-N28 systems are listed in Table 1-4.
Specification AFL2-10A-N28
LCD Size 10.4"
Max. Resolution 800 (W) x 600 (H)
Brightness (cd/m2) 400
Contrast Ratio 700:1
LCD Color 262K/16.2M
Pixel Pitch (H x V) (mm) 0.264 (H) x 0.264 (V)
Viewing Angle (H-V) 160° / 140°
Backlight LED backlight (MTBF: 30,000 hrs)
Touchscreen 5-Wire resistive type touch screen
CPU 1.86 GHz Intel® Atom™ N2800 dual-core processor
Chipset Intel® NM10
Ethernet Realtek RTL8111E PCIe GbE controller support ASF2.0
Memory Preinstalled one 204-pin 1066 MHz 2 GB DDR3 SO-DIMM (max. 4 G)
HDD 2.5" SATA 3Gb/s HDD bay
Audio Realtek ALC892 HD Audio codec (Line-out)
Speaker AMP 1.5 W + 1.5 W (built-in stereo speakers)
Camera 2-megapixel camera with low light function
Microphone Digital microphone located on the bottom of the front frame
Wireless 1 x Wireless LAN 802.11 b/g/n module (PCIe Mini card)
Bluetooth Optional internal USB interface, Bluetooth V2.0+EDR
RFID Reader EM 125 KHz or MIFARE 13.56 MHz card reader (optional)
MSR Card Reader MSR card reader (optional)
