AFL2-10A-N28 Panel PC

Page 6

1.2.1.2 Function Keys

The function keys are located under the bottom right hand corner of the LCD screen

(Figure 1-4).

Figure 1-4: Function Keys

The function keys are described in Table 1-3:

Key Combination

Function Key Description

Fn

Function key.

Fn + LCD On/Off

Enable/Disable RFID

Fn + Audio Volume Down

Mute audio

Fn + Audio Volume Up

Enable/Disable camera

Fn + Brightness Down

Enable/Disable Mini USB or microSD

Fn + Brightness Up

Power On/Off

Note: To power on the system, hold down the Fn +

Brightness Up buttons for six seconds. To power down the

system, hold down the Fn + Brightness Up buttons for

eight seconds.

Table 1-2: Function Key Descriptions
