AFL2-10A-N28 Panel PC
Page 31
Step 7: Tighten the screws that pass through the panel mounting clamps until the plastic
caps at the front of all the screws are firmly secured to the panel.
Step 8: Install the covers into the panel mounting bracket. Each mounting bracket
includes two side covers and one top cover (Figure 3-16
p
).
Figure 3-16: Tighten the Panel Mounting Clamp Screws
3.11.3 Cabinet and Rack Installation
The AFL2-10A-N28 flat bezel panel PC can be installed into a cabinet or rack. The
installation procedures are similar to the panel mounting installation. To do this, please
follow the steps below:
