AFL2-10A-N28 Panel PC
Page 34
Step 8: Once the flat bezel panel PC with the attached rack/cabinet bracket has been
properly inserted into the rack or cabinet, secure the front of the rack/cabinet
bracket to the front of the rack or cabinet (Figure 3-19).
3.11.4 Arm Mounting
The AFL2-10A-N28 is VESA (Video Electronics Standards Association) compliant and can
be mounted on an arm with a 75 mm interface pad. To mount the AFL2-10A-N28 on an
arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that
the arm has a 75 mm interface pad. If the mounting arm is not VESA
compliant it cannot be used to support the AFL2-10A-N28 flat bezel panel
PC.
Step 2: Once the mounting arm has been firmly attached to the surface, lift the flat bezel
panel PC onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
flat bezel panel PC (Figure 3-20).
