AFL2-10A-N28 Panel PC

Page 108

6.5 Replacing Components

6.5.1 Memory Module Replacement

The flat bezel panel PC is preinstalled with one 2.0 GB DDR3 memory module. If the

memory module fails, follow the instructions below to replace the memory module.

Step 1:

Follow all anti-static procedures. See Section 6.2.

Step 2:

Turn off the power. See Section 6.3.

Step 3:

Remove the back cover. See Section 6.4.1 above.

Step 4:

Remove the internal back cover. See Section 6.4.2 above.

Step 5:

Locate the DDR3 SO-DIMM on the motherboard.

Step 6:

Remove the DDR3 memory module by pulling both the spring retainer clips

outward from the socket.

Step 7:

Grasp the DDR3 memory module by the edges and carefully pull it out of the

socket.

Step 8:

Install the new DDR3 memory module by pushing it into the socket at an angle

Step 9:

Gently pull the spring retainer clips of the SO-DIMM socket out and push the

rear of the DDR memory module down (Figure 6-4).

Step 10:

Release the spring retainer clips on the SO-DIMM socket. They clip into place

and secure the DDR memory module in the socket.
