AFL2-10A-N28 Panel PC

Page 121

17 VCC3

18 VCC_LCD

19 VCC_LCD 20 VCC_LCD

Table 7-12: LVDS Connector (LCD1) Pinouts

7.2.12 LVDS Backlight Connector (INVERTER1)

PIN NO.

DESCRIPTION

1 BRIGHTNESS

2 GND

3 BKL_POWER

4 GND

5 ENABKL

Table 7-13: LVDS Backlight Connector (INVERTER1) Pinouts

7.2.13 microSD Connector (MICRO_SD1)

PIN NO.

DESCRIPTION

1 VCC_MSD

2 -DATA3

3 +DATA3

4 GND

5 VCC3

Table 7-14: microSD Connector (MICRO_SD1) Pinouts

7.2.14 Mini USB Connector (MINI_USB1)

PIN NO.

DESCRIPTION

1 VCC_MINIUSB

2 -DATA2

3 +DATA2

4 GND

Table 7-15: Mini USB Connector (MINI_USB1) Pinouts
