Before the IMB-Q354 is installed in the system, the jumpers must be set in accordance
with the desired configuration. The jumpers on the IMB-Q354 are listed in Table 4-1.
Description Label Type
Clear CMOS J_CMOS1 3-pin header
COM2 pin 9 setting J_COM_F2 3-pin header
COM3 pin 9 setting J_COM_F3 3-pin header
COM4 pin 9 setting J_COM_F4 3-pin header
COM2 pin 9 voltage setting J_COM_V2 3-pin header
COM3 pin 9 voltage setting J_COM_V3 3-pin header
COM4 pin 9 voltage setting J_COM_V4 3-pin header
Table 4-1: Jumpers
4.5.1 Clear CMOS Jumper
Jumper Label: J_CMOS1
Jumper Type: 3-pin header
Jumper Settings: See Table 4-2
Jumper Location: See Figure 4-9
If the IMB-Q354 fails to boot due to improper BIOS settings, the clear CMOS jumper
clears the CMOS data and resets the system BIOS information. To do this, use the jumper
cap to close pins 2 and 3 for a few seconds then reinstall the jumper clip back to pins 1
and 2.
If the “CMOS Settings Wrong” message is displayed during the boot up process, the fault
may be corrected by pressing the F1 to enter the CMOS Setup menu. Do one of the
following:
Enter the correct CMOS setting
Load Optimal Defaults
