IMB-Q354 microATX Motherboard

Page 178

To access an Intel® AMT client system from a remote console, follow the steps below.

Step 1:

Obtain the IP address of the client system.

Step 2:

On the remote management console, open a web browser.

Step 3:

If DHCP is enabled in the TCP/IP menu of the Intel® ME BIOS (Section 7.2,

Step 10

), get the client system IP address in the MS DOS. Enter the client

system IP address and the port number in the web browser:

http://ip_address:16992 Example: http://192.168.1.7:16992 (Figure 7-11)

Or simply enter the defined host name: http://host_name:16992

Example: http://AMTsystem:16992

Figure 7-11: Intel® AMT Web Address

Step 4:

If a static IP address is defined for the Intel® AMT client system, enter the

defined client system IP address and the port number in the web browser.

Step 5:

A login window prompts (Figure 7-12).
