IMB-Q354 microATX Motherboard
Page 31
Serial ATA drive connector 7-pin SATA SATA3
Serial ATA drive connector 7-pin SATA SATA4
Serial ATA drive connector 7-pin SATA SATA5
Serial ATA drive connector 7-pin SATA SATA6
Serial port connector (COM2) 10-pin box header COM2
Serial port connector (COM3) 10-pin box header COM3
Serial port connector (COM4) 10-pin box header COM4
SPDIF connector 5-pin header SPDIF1
SPI flash connector 8-pin header JSPI1
TPM connector 20-pin header TPM1
USB connector 8-pin header USB45
USB connector 8-pin header USB67
USB connector 8-pin header USB89
USB connector 8-pin header USB1011
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
Table 3-2 lists the rear panel connectors on the IMB-Q354. Detailed descriptions of these
connectors can be found in Section 3.3.
Connector Type Label
Audio connector Audio jack AUDIO_CV1
Ethernet and dual USB combo connector RJ-45 and two USB LAN1_USB01
Ethernet and dual USB combo connector RJ-45 and two USB LAN2_USB23
Mouse or keyboard connector PS/2 KB_MS1
