IMB-Q354 microATX Motherboard
Page 23
Four by external connectors
SATA Six SATA 3Gb/s drives supported
SATA RAID Levels RAID 0, RAID 1, RAID 5 and RAID 10
Keyboard/mouse By external PS/2 connector through the ITE IT8712F super I/O
Digital I/O
One 8-bit digital input/output connector; 4-bit input/4-bit output
through the ITE IT8712F super I/O
Watchdog Timer
Software programmable 1-255 sec. through the ITE IT8712F
super I/O
Infrared One infrared connector through the ITE IT8712F super I/O.
Power Supply ATX power supply
TPM Supports TPM v1.2 with 20-pin onboard pin-header
Fan Connector
One system fan 3-pin header
One CPU fan 4-pin header
Buzzer Yes
Power Consumption
[email protected], [email protected], [email protected] (3Dmark® 2001) and
[email protected] (3.0 GHz E6850 Intel® Core™2 Duo CPU with
four 2.0 GB, 800 MHz DDR2 DIMM running 3Dmark® 2001)
Temperature 0ºC – 60ºC (32ºF - 140ºF)
Humidity (Operating) 5%~95% non-condensing
Dimensions (LxW) 244 mm x 244 mm
Weight (GW) 1.1 kg
Table 1-1: Technical Specifications
