IMB-Q354 microATX Motherboard
Page 103
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Event Monitoring
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU_FAN1 Mode Setting
[Full On Mode]
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature
:46ºC/114ºF
PWM Temperature :29ºC/84ºF
System Temperature :31ºC/87ºF
CPU_FAN1 Speed
:3260 RPM
SYS_FAN1 Speed :N/A
CPU Core
:1.264 V
DDR2 1.8V :1.904 V
+3.30V :3.280 V
+5.00V :4.892 V
+12.0V :11.968 V
FSB +1.2V :1.168 V
+1.5V :1.488 V
+1.25V :1.232 V
VBAT :3.008 V
Fan configuration mode
setting
Select Screen
↑ ↓ Select
Item
+ - Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 8: Hardware Health Configuration
CPU_FAN1 Mode Setting [Full On Mode]
Use the CPU_FAN1 Mode Setting option to configure the second fan.
Full On Mode Fan is on all the time
Automatic mode D EFAULT Fan is off when the temperature is low
enough. Parameters must be set by the
user.
PWM Manual mode Pulse width modulation set manually
The following system parameters and values are shown. The system parameters that are
monitored are:
System Temperatures: The following system temperatures are monitored
o CPU Temperature
o PWM Temperature
o System Temperature
