IMB-Q354 microATX Motherboard
Page 172
7.1 Intel
®
AMT Setup Procedure
The IMB-Q354 is featured with the Intel® Active Management Technology (AMT). To
enable the Intel® AMT function, follow the steps below.
Step 1: Make sure the DIMM1 socket is installed with one DDR2 DIMM.
Step 2: Connect an Ethernet cable to the RJ-45 connector labeled LAN2_USB23.
Step 3: The AMI BIOS options regarding the Intel® ME or Intel® AMT must be enabled,
including:
Intel® AMT Configuration [Advanced] (see Section 5.3.8)
ME Subsystem Configuration [Advanced] (see Section 5.3.8.1)
Step 4: Configure the Intel® Management Engine BIOS extension (MEBx)
(see Section 7.2 below)
Step 5: Properly install the Intel® AMT drives. Make sure to install both HECI and
LMS_SOL drivers from the iAMT Driver & Utility directory in the driver CD (see
Section 6.9).
Step 6: The following dialog window is displayed after the OS is loaded to show the
Intel® AMT status on the IMB-Q354 is enabled. Step 0:
Figure 7-1: Intel® Active Management Technology Status Dialog
