BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
North Bridge Chipset Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Memory Remap Feature
[Enabled]
PCI MMIO Allocation: 4GB to 3072MB
Memory Hole [Disabled]
Initate Graphic Adapter
[PEG/PCI]
Internal Graphics Mode Select [Enabled, 8MB]
Select Screen
↑ ↓ Select
Item
+ - Change Field
Tab Select Field
F1 General Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 26: North Bridge Configuration
Memory Remap Feature [Enabled]
Use the Memory Remap Feature option to allow the overlapped PCI memory above the
total physical memory to be remapped.
Disabled Overlapped PCI memory cannor be remapped
Enabled D EFAULT Overlapped PCI memory can be remapped
Memory Hole [Disabled]
Use the Memory Hole option to reserve memory space between 15MB and 16MB for ISA
expansion cards that require a specified area of memory to work properly. If an older ISA
expansion card is used, please refer to the documentation that came with the card to see if
it is necessary to reserve the space.
Disabled D EFAULT Memory is not reserved for ISA expansion cards
15MB – 16MB Between 15MB and 16MB of memory is reserved for
ISA expansion cards
