IMB-Q354 microATX Motherboard
Page 39
3.2.7 Front Audio Connector
CN Label: FRONT_PANEL1
CN Type: 10-pin header (2x5)
CN Location: See Figure 3-8
CN Pinouts: See Table 3-9
Figure 3-8: Front Audio Connector Location (10-pin)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 MIC_L 2 GND
3 MIC_R 4 Audio Detect
5 LINE2-R 6 GND
7 Jack Detection 8 N/C
9 LINE2-L 10 GND
Table 3-9: Front Audio Connector Pinouts
