IMB-Q354 microATX Motherboard
Page 60
4.4.1 Socket LGA775 CPU Installation
NOTE:
Enabling Hyper-Threading Technology on your system requires
meeting all of the platform requirements listed below:
CPU: An Intel® Processor with HT Technology must be
installed
Chipset: An Intel® Chipset that supports HT Technology
(that has been met by the IMB-Q354)
OS: An operating system that has optimizations for HT
Technology
WARNING:
CPUs are expensive and sensitive components. When installing the
CPU please be careful not to damage it in anyway. Make sure the CPU
is installed properly and ensure the correct cooling kit is properly
installed.
The LGA775 socket is shown in Figure 4-1.
Figure 4-1: Intel® LGA775 Socket
To install a socket LGA775 CPU onto the IMB-Q354, follow the steps below:
