KINO-AH612
Page 87
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Chipset
Auto Power Button Status [OFF]
Wake Event Configuration
Restore AC Power Loss [Power Off]
Resume on PCI WAKE [Enabled]
Resume on PME/GbE [Enabled]
Resume on Ring [Enabled]
Resume on PS/2 [Enabled]
Audio Configuration
Azalia HD Audio [Enabled]
Azalia internal HDMI codec [Enabled]
Specify what state to go
to when power is
re-applied after a power
failure (G3 state).
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 19: Southbridge Chipset Configuration
Î Restore AC on Power Loss [Power Off]
Use the Restore AC on Power Loss option to specify what state the system returns to if
there is a sudden loss of power to the system.
Î
Power Off D EFAULT The system remains turned off
Î
Power On The system turns on
Î
Last State The system returns to its previous state. If it was on,
it turns itself on. If it was off, it remains off.
Î Resume on PCIE Wake [Enabled]
Use the Resume on PCIE Wake option specifies if the system is roused from a
suspended or standby state when there is activity on the LAN.
Î
Disabled Disables Resume on PCIe Wake
Î
Enabled D EFAULT Enables Resume on PCIe Wake
