KINO-AH612
Page 15
3.1.2 Peripheral Interface Connectors
The following table lists all the connectors on the board.
Connector Type Label
ATX power supply 24-pin ATX ATX1
Audio connector 10-pin header FP_AUDIO1
Battery connector 2-pin wafer BT1
BIOS update connector 6-pin header JSPI1
DDR3 SO-DIMM slots DDR3 SO-DIMM slot DIMM1, DIMM2
Digital I/O connector 10-pin header DIO1
Fan connector (CPU) 4-pin wafer CPU_FAN1
Fan connector (System) 3-pin wafer SYS_FAN1
Front Panel connector 14-pin header F_PANEL
I2C connector 4-pin wafer I2C_1
Keyboard/mouse connector 6-pin wafer KB_MS1
PCIe x4 slot PCIe x4 slot PCIEX41
Power connector 4-pin connector CPU_12V
SATA drive connector
Serial ATA (SATA)
3Gb/s Connector
SATA1, SATA2, SATA3,
SATA4
Serial port connector (RS-232) 10-pin header COM3, COM5, COM6
Serial port connector (RS-422/RS-485) 4-pin wafer COM4
SMBus connector 4-pin wafer SMBUS_1
TPM connector 20-pin header TPM1
USB connector 8-pin header USB1, USB2
Table 3-1: Peripheral Interface Connectors
