KINO-AH612
Page 7
Specification KINO-AH612
Keyboard/Mouse One internal keyboard and mouse connector via 6-pin wafer
TPM One 20-pin header
Fan One 4-pin CPU fan connector
One 3-pin system fan connector
Serial Ports One internal RS-422/485 via internal 4-pin wafer
USB Ports Four external USB 2.0 ports by rear IO
Four internal USB 2.0 ports via 8-pin header
Storage
Serial ATA Four SATA 3Gb/s connectors
Environmental and Power Specifications
Power Supply ATX power supply
Power Consumption [email protected], [email protected], [email protected], [email protected],
[email protected] (3.4GHz Intel® Core™ i7-2600 with 2GB*2
DDR3 1333MHz)
Operating Temperature -10ºC ~ 60ºC
Storage Temperature -20ºC ~ 70ºC
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 170 mm x 170 mm
Weight GW/NW 1100 g / 700 g
Table 1-1: Technical Specifications
