ƒ L2 Cache: Lists the amount of storage space on the L2 cache.
ƒ L3 Cache: Lists the amount of storage space on the L3 cache.
5.3.4 SATA Configuration
Use the SATA Configuration menu (BIOS Menu 7) to change and/or set the
configuration of the SATA devices installed in the system.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
SATA Configuration
SATA Mode
[IDE Mode]
Serial-ATA Controller 0 [Compatible]
Serial-ATA Controller 1 [Enhanced]
SATA Port0 Not Present
SATA Port1
Not Present
SATA Port4
Not Present
SATA Port5
Not Present
(1) IDE Mode.
---------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 7: IDE Configuration
Î SATA Mode [IDE Mode]
Use the SATA Mode option to configure SATA devices as normal IDE devices.
Î
Disabled Disables SATA devices.
Î
IDE Mode D EFAULT Configures SATA devices as normal IDE device.
Î
AHCI Mode Configures SATA devices as an AHCI device.
Î Serial-ATA Controller 0 [Compatible]
Use the Serial-ATA Controller 0 option to configure the Serial-ATA controller mode when
the SATA mode is set to IDE Mode.
Î
Disabled Disables Serial-ATA controller.
