KINO-AH612

Page 16

3.1.3 External Interface Panel Connectors

The table below lists the connectors on the external I/O panel.

Connector

Type

Label

Audio connector

Audio jack

AUDIO_CV1

Ethernet + USB connector

RJ-45, USB port

LANUSB1,

LANUSB2

Keyboard and PS/2 Mouse connector

Dual PS/2 port

KB_MS2

Serial port connectors

Dual DB-9 port

COM1, COM2

DVI-D + VGA connector

DVI + 15-pin

female

VIDEO1

Table 3-2: Rear Panel Connectors

3.2 Internal Peripheral Connectors

The section describes all of the connectors on the KINO-AH612.

3.2.1 ATX Power Supply Connector

CN Label:

ATX1

CN Type:

24-pin connector

CN Location:

See Figure 3-2

CN Pinouts:

See Table 3-3

The ATX power connector connects to an ATX power supply.
