KINO-AH612
Page 6
1.5 Technical Specifications
KINO-AH612 technical specifications are listed in table below.
Specification KINO-AH612
Form Factor Mini-ITX
Socket LGA1155
CPU Supported Socket 1155 Intel® Core™ i7/i5/i3/Pentium®/Celeron® dual
core processor
System Chipset Intel® H61
Memory Two 204-pin 1066/1333 MHz dual-channel DDR3 SO-DIMM
supported (system max. 16 GB)
Graphics Engine Support for DX10.1 and OpenGL3.0, full MPEG2. VC1. AVC
decode
Audio Realtek ALC662 HD Audio codec
LAN Two Realtek RTL8111E PCIe GbE controllers with ASF 2.0
support
Embedded Controller iWDD
Super I/O Fintek F81866
Digital I/O 8-bit digital I/O, 4-bit input/4-bit output
BIOS UEFI BIOS
Watchdog Timer Software programmable supports 1~255 sec. system reset
Expansions
PCIe One PCIe x4 slot
I/O Interface Connectors
Audio Connector Two external audio jacks (Line-out, Mic)
Display Ports One VGA integrated in Intel® H61
One DVI-D integrated in Intel® H61
Ethernet Two RJ-45 GbE ports
