KINO-AH612
Page 65
5.3.3.1 CPU Information
Use the CPU Information submenu (BIOS Menu 6) to view detailed CPU specifications
and configure the CPU.
Aptio Setup Utility – Copyright (C) 2011 American Megatrends, Inc.
Advanced
CPU Configuration
Intel(R) Pentium(R) CPU G850 @ 2.90GHz
CPU Signature
206a7
Microcode Patch 14
Max CPU Speed 2900 MHz
Min CPU Speed 1600 MHz
Processor Cores 2
Intel HT Technology Not Supported
Intel VT-x Technology Supported
Intel SMX Technology Not Supported
L1 Data Cache
32 kB x 2
L1 Code Cache 32 kB x 2
L2 Cache 256 kB x 2
L3 Cache 3072 kB
----------------------
ÅÆ: Select Screen
↑ ↓: Select Item
Enter
Select
+/-: Change Opt.
F1: General
Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.11.1210. Copyright (C) 2011 American Megatrends, Inc.
BIOS Menu 6: CPU Configuration
The CPU Configuration menu (BIOS Menu 6) lists the following CPU details:
ƒ Processor Type: Lists the brand name of the CPU being used
ƒ CPU Signature: Lists the CPU signature value.
ƒ Microcode Patch: Lists the microcode patch being used.
ƒ Max CPU Speed: Lists the maximum CPU processing speed.
ƒ Min CPU Speed: Lists the minimum CPU processing speed.
ƒ Processor Cores: Lists the number of the processor core
ƒ Intel HT Technology: Indicates if Intel HT Technology is supported by the
CPU.
ƒ Intel VT-x Technology: Indicates if Intel VT-x Technology is supported by the
CPU.
ƒ Intel SMX Technology: Indicates if Intel SMX Technology is supported by the
CPU.
ƒ L1 Data Cache: Lists the amount of data storage space on the L1 cache.
ƒ L1 Code Cache: Lists the amount of code storage space on the L1 cache.
