KINO-945GSE2 Motherboard
Page 84
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
Configure Super I/O Chipset
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Serial Port1 Address
[3F8]
Serial Port1 IRQ [IRQ4]
Serial Port2 Address [2F8]
Serial Port2 IRQ [IRQ3]
Serial Port3 Address [3E8]
Serial Port3 IRQ [IRQ4]
Serial Port4 Address [2E8]
Serial Port4 IRQ [IRQ3]
Select RS232 or RS422/485 [RS232]
Serial Port5 Address [3E0]
Serial Port5 IRQ [IRQ5]
Serial Port6 Address [2E0]
Serial Port6 IRQ [IRQ5]
> COM6 Function
Parallel Port Address
[378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]
Allows BIOS to select
Serial Port Base
Addresses
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 6: Super IO Configuration
Serial Port 1 Address [3F8]
Sets the port address of serial port 1.
Disabled
3F8 D EFAULT
2F8
3E8
2E8
Serial Port 1 IRQ [IRQ4]
Sets the interrupt address of serial port 1.
IRQ4 D EFAULT
Serial Port 2 Address [2F8]
Sets the port address of serial port 2.
