KINO-945GSE2 Motherboard
Page 89
5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu shows the operating temperature, fan speeds
and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Power Exit
Hardware Health Event Monitoring
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU Temperature
:63ºC/145ºF
System Temperature :37ºC/98ºF
CPU Fan1
:N/A
VCC_CORE :1.192
V
VCC5 :4.624 V
VCC12 :11.880 V
+1.8V_DDR2 :1.824 V
VCC3 :3.312 V
VCC3DUAL :3.328 V
+V3.3A_RTC :3.200 V
CPU_FAN1 Mode Setting
[Auto Fan by RPM]
CPU Temp. Limit of Highest [050]
CPU Temp. Limit of Second [040]
CPU Temp. Limit of Third [030]
CPU Temp. Limit of Lowest [020]
CPU_Fan1 Highest setting [100]
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
Mode Setting [Full On Mode]
Use the Mode Setting option to configure the second fan.
Auto Fan by RPM The fan adjusts its speed using these settings:
Limit of highest
Limit of second
Limit of third
Limit of lowest
CPU_Fan1 Highest setting
