KINO-945GSE2 Motherboard
Page 9
1.6 Technical Specifications
KINO-945GSE2 technical specifications are listed in
5
Table 1-1.
Specification KINO-945GSE2
Form Factor Mini-ITX
System CPU 45 nm 1.60 GHz Intel® Atom™ N270
Front Side Bus (FSB) 533 MHz
System Chipset Northbridge: Intel® 945GSE
Southbridge: Intel® ICH7M
Memory One 200-pin SO-DIMM socket supports one 533 MHz
2.0 GB (max.) DDR2 SDRAM SO-DIMM
Super I/O Fintek 81865
Display 1 x VGA
2 x LVDS
1 x HDTV
BIOS AMI BIOS label
Audio Realtek ALC655 AC'97 codec
LAN Two Realtek RTL8111CP PCIe GbE controllers
COM Four RS-232 serial ports (one external, three internal)
Two RS-232/422/485 serial port (internal)
USB2.0 Six USB 2.0 devices supported (two internal, four external)
SATA Two 1.5 Gb/s SATA drives supported
Keyboard/mouse One external PS/2 connector (split using included cable)
Digital I/O One 8-bit digital input/output connector; 4-bit input/4-bit
output through the Fintek 81865 super I/O
Watchdog Timer Software programmable 1-255 sec. through the Fintek
81865 super I/O
Infrared One infrared connector supports
Serial Infrared (SIR)
Amplitude Shift Keyed IR (ASKIR)
