KINO-GM45A Mini-ITX SBC
Page 82
5.3.4 Hardware Health Configuration
The Hardware Health Configuration menu (BIOS Menu 7) shows the operating
temperature, fan speeds and system voltages.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Hardware Health Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
CPU_FAN1 Mode Setting
[Full On Mode]
CPU Temperature
:52ºC/127ºF
System Temperature :36ºC/96ºF
PWM Temperature :21ºC/69ºF
CPU_Fan Speed
:5976 RPM
FAN1 Speed :N/A
CPU Core
:1.280 V
+1.05V :1.072 V
+3.30V :3.328 V
+5.00V :5.107 V
+12.0V :11.904 V
+1.5V :1.520 V
+1.8V :1.952 V
+5VSB :5.134 V
VBAT :3.232 V
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 7: Hardware Health Configuration
5.3.5 AHCI Configuration
NOTE:
Advanced Host Controller Interface (AHCI) is a new programming
interface for SATA host controllers. AHCI systems do not have
master/slave designation for SATA devices, each device is treated as a
master, and hardware-assisted native command queuing.
