KINO-GM45A Mini-ITX SBC
Page 39
7 HDMI_DATA0 19 HDMI_HPD
8 GND 20 HDMI_GND
9 HDMI_DATA0# 21 HDMI_GND
10 HDMI_CLK 22 HDMI_GND
11 GND 23 HDMI_GND
12 HDMI_CLK#
Table 3-23: HDMI Connector Pinouts
3.3.4 TV Connector
CN Label: TV1
CN Type: 7-pin Mini-DIN
CN Location: See Figure 3-20
CN Pinouts: See Table 3-24
A 7-pin mini DIN connector is located on the mounting bracket for easy connection to a TV
OUT cable.
PIN NO. DESCRIPTION
1 GND
2 BLUE_CVBS
3 GND
4 GREEN_Y
5 NC
6 RED_C
7 GND
Table 3-24: TV1 Pinouts
3.3.5 USB Connectors
CN Label: USB_C01
CN Type: USB port
