ƒ Brand String: Lists the brand name of the CPU being used
ƒ Frequency: Lists the CPU processing speed
ƒ FSB Speed: Lists the FSB speed
ƒ Cache L1: Lists the CPU L1 cache size
ƒ Cache L2: Lists the CPU L2 cache size
5.3.2 IDE Configuration
Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration
of the IDE devices installed in the system.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
IDE Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
SATA#1 Configuration
[Compatible]
Configure SATA#1 as [IDE]
> Primary IDE Master
: [Not Detected]
> Secondary IDE Master : [Not Detected]
DISABLED: disable the
integrated IDE
controller.
PRIMARY: enables only
the Primary IDE
controller
SECONDARY: enables only
the Secondary IDE
controller.
BOTH: enables both IDE
controllers
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 4: IDE Configuration
Î SATA#1 Configurations [Compatible]
Use the SATA#1 Configurations option to configure the ATA/IDE controller.
Î
Disabled Disables the on-board ATA/IDE controller.
