KINO-GM45A Mini-ITX SBC
Page 17
Serial ATA (SATA) drive connector 7-pin SATA S_ATA2
SATA power connector 4-pin wafer CN6
SATA power connector 4-pin wafer CN7
SPDIF connector 5-pin header SPDIF1
SPI Flash connector 8-pin header JSPI1
USB connector (1) 8-pin header USB23
USB connector (2) 8-pin header USB45
USB connector (3) 8-pin header USB67
Table 3-1: Peripheral Interface Connectors
3.1.3 External Interface Panel Connectors
The table below lists the connectors on the external I/O panel.
Connector Type Label
Audio speaker out jack Audio jack SPEAKOUT1
Ethernet connector RJ-45 LAN1
HDMI port HDMI Type A port HDMI1
Power connector (12V, power adapter) 4-pin Mini-DIN PWR1
TV out connector 7-pin Mini-DIN TV1
USB ports (dual) USB port USB_C01
VGA port connector 15-pin female VGA1
Table 3-2: Rear Panel Connectors
