KINO-GM45A Mini-ITX SBC
Page 27
19 N/C 20 N/C
21 GND 22 PCIRST#
23 PERN2 24 3VDual
25 PERP2 26 GND
27 GND 28 1.5V
29 GND 30 SMBCLK
31 PETN2 32 SMBDATA
33 PETP2 34 GND
35 GND 36 USBD-
37 N/C 38 USBD+
39 N/C 40 GND
41 N/C 42 N/C
43 N/C 44 N/C
45 N/C 46 N/C
47 N/C 48 1.5V
49 N/C 50 GND
51 N/C 52 3.3V
Table 3-11: PCIe Mini Card Slot Pinouts
3.2.10 PCIe Mini Card Expansion Connector
CN Label: JP6
CN Type: 48-pin header (2x24)
CN Location: See
4
Figure 3-10
CN Pinouts: See Table 3-11
The PCIe Mini card expansion connector is for installing the optional PCIe Mini expansion
kit (IO-KIT-MPCIE-R10) which can support two additional PCIe/USB mini cards.
