4.6 Chassis Installation
4.6.1 Airflow
WARNING:
Airflow is critical to the cooling of the CPU and other onboard
components. The chassis in which the KINO-GM45A must have air
vents to allow cool air to move into the system and hot air to move out.
The KINO-GM45A must be installed in a chassis with ventilation holes on the sides
allowing airflow to travel through the heat sink surface. In a system with an individual
power supply unit, the cooling fan of a power supply can also help generate airflow
through the board surface.
4.6.2 Motherboard Installation
To install the KINO-GM45A motherboard into the chassis please refer to the reference
material that came with the chassis.
4.7 Internal Peripheral Device Connections
This section outlines the installation of peripheral devices to the onboard connectors
4.7.1 Audio Kit Installation
The Audio Kit that came with the KINO-GM45A connects to the audio connector on the
KINO-GM45A. The audio kit consists of three audio jacks. Mic-in connects to a
microphone. Line-in provides a stereo line-level input to connect to the output of an
audio device. Line-out, a stereo line-level output, connects to two amplified speakers. To
install the audio kit, please refer to the steps below:
Step 1: Locate the audio connector. The location of the 10-pin audio connector is
shown in Chapter 3.
