KINO-GM45A Mini-ITX SBC
Page 98
5.7.1 Northbridge Configuration
Use the Northbridge Chipset Configuration menu (BIOS Menu 19) to configure the
Northbridge chipset.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
Northbridge Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Memory Hole
[Disabled]
Boots Graphic Adapter Priority [IGD]
nternal Graphics Mode Select
[Enabled, 32MB]
Boot Display Device
[Auto]
Flat Panel Type [BY HARDWARE]
Current Jumper Setting [ 640x480 18b]
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 19:Northbridge Chipset Configuration
Î Memory Hole [Disabled]
Use the Memory Hole option to reserve memory space between 15 MB and 16 MB for
ISA expansion cards that require a specified area of memory to work properly. If an older
ISA expansion card is used, please refer to the documentation that came with the card to
see if it is necessary to reserve the space.
Î
Disabled D EFAULT Memory is not reserved for ISA expansion cards
Î
15 MB – 16 MB Between 15 MB and 16 MB of memory is reserved
for ISA expansion cards
