Before the KINO-GM45A is installed in the system, the jumpers must be set in accordance
with the desired configuration. The jumpers on the KINO-GM45A are listed in
5
Table 4-1.
Description Type Label
AT Power Mode Setting 2-pin wafer ATXCTL1
Clear CMOS 3-pin header J_CMOS1
COM2 Function Select 8-pin header JP5
LVDS Panel Resolution 8-pin header JP1
LVDS Voltage Select 3-pin header J_VLVDS1
Table 4-1: Jumpers
4.5.1 AT Power Select Jumper Settings
Jumper Label: ATXCTL1
Jumper Type: 3-pin header (1x3)
Jumper Settings: See Table 4-2
Jumper Location: See Figure 4-6
The AT Power Select jumper specifies the systems power mode as AT or ATX. AT Power
Select jumper settings are shown in Table 4-2.
AT Power Select Description
Short 2 – 3 Use AT power Default
Short 1 - 2 Use ATX power
Table 4-2: AT Power Select Jumper Settings
The location of the AT Power Select jumper is shown in Figure 4-6 below.
