Page 76: Figure 4-16: vga connector

KINO-GM45A Mini-ITX SBC

Page 64

Figure 4-16: VGA Connector

Step 4:

Secure the connector. Secure the DB-15 VGA connector from the VGA

monitor to the external interface by tightening the two retention screws on either

side of the connector.

Step 0:

4.9 Software Installation

All the drivers for the KINO-GM45A are on the CD that came with the system. To install

the drivers, please follow the steps below.

Step 1:

Insert the CD into a CD drive connected to the system.

NOTE:

If the installation program doesn't start automatically:

Click "Start->My Computer->CD Drive->autorun.exe"

Step 2:

The driver main menu appears (Figure 4-17).
