KINO-GM45A Mini-ITX SBC
Page 90
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
ACPI Settings
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
Suspend mode
[S1 (POS)]
Set the ACPI state used
for System suspend
ÅÆ Select
Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 13: ACPI Configuration
Î Suspend Mode [S1(POS)]
Use the Suspend Mode option to specify the sleep state the system enters when it is not
being used.
Î
S1 (POS) D EFAULT The system enters S1(POS) sleep state. The system
appears off. The CPU is stopped; RAM is refreshed;
the system is running in a low power mode.
Î
S3(STR) The caches are flushed and the CPU is powered off.
Power to the RAM is maintained. The computer
returns slower to a working state, but more power is
saved.
