KINO-GM45A Mini-ITX SBC
Page 8
Specification KINO-GM45A
Display Ports One VGA port
One 18-bit or 24-bit dual-channel LVDS port
One TV-out port supports HDTV
One external HDMI port supports up to 1080p
Ethernet One RJ-45 GbE port
Serial Ports Three RS-232 via three 10-pin header connectors
One RS-232/422/485 via 14-pin header connector
USB 2.0/1.1 Ports Eight external USB ports
Storage
Serial ATA Two independent serial ATA (SATA) channels with 3.0 Gb/s
data transfer rates
Environmental and Power Specifications
Power Supply 12 V only
ATX and AT power supported
Power Connector One internal 4-pin Molex power connector for power supply
One external 4-pin Mini-DIN for power adapter
Power Consumption [email protected]
2.0 GHz Intel® Core™2 Quad Q9000 CPU with two 800 MHz
1 GB DDR2 SO-DIMM
Operating Temperature 0ºC ~ 60ºC (requires cooler and silicone heat sink paste)
Humidity 5% ~ 95% (non-condensing)
Physical Specifications
Dimensions 170 mm x 170 mm
Weight GW/NW 1000g/390g
Table 1-1: Technical Specifications
